- Engine type
- Liquid-cooled, 4-stroke Single
- Displacement
- 443 cm³
- Bore x stroke
- 89.0 x 71.2 mm
- Compression ratio
- 9.1:1
- Valve system
- SOHC, 4 valves per cylinder
- Fuel system
- Fuel injection: ø38 mm x 1
- Ignition
- ECU control (full transistor)
- Starting System
- Electric
- Lubrication
- Forced lubrication, wet sump
- Maximum power
- 24 kW {33 PS} / 7,000 rpm
- Maximum torque
- 33 N•m {3.4 kgf•m} / 6,500 rpm
- Transmission
- Dual range (high/low) CVT with reverse
- Final drive
- Shaft 2WD/4WD, dual-mode front differential
- Primary Reduction Ratio
- 3.110 ~ 0.800 (belt converter)
- Primary drive
- Belt converter
- Gear Ratio Forward
- 3.495 (High), 6.827 (Low)
- Gear Ratio Reverse
- 5.461
- Final reduction ratio
- 3.091 (Front), 3.091 (Rear)
- Parking Brake
- Rear disc (mechanical)
- Brakes, front
- Dual 202 mm discs with single piston calipers
- Brakes, rear
- 202 mm disc with single piston caliper
- Suspension, front
- Dual A-arm, adjustable spring preload
- Suspension, rear
- Dual A-arm, adjustable spring preload
- Frame type
- Double cradle, high-tensile tubular steel
- Trail
- 11 mm
- Wheel travel front
- 194 mm
- Wheel travel rear
- 201 mm
- Tyre, front
- AT 24 x 8-12
- Tyre, rear
- AT 24 x 10-12
- Steering angle, left / right
- 42° / 42°
- L x W x H
- 2,035 x 1,110 x 1,185 mm
- Wheelbase
- 1,215 mm
- Ground clearance
- 235 mm
- Fuel capacity
- 16 litres
- Seat height
- 880 mm
- Curb mass
- 310 kg
|
|
Price
£5,328.00
( £6,393.60 tax incl.) |
|
|
|
|
|
|
|
|
